e. The steam is exhausted at each end of the valve bydirect passages which quickly free the cylinder. The piston ishollow, fastened by a taper fit to the rod, and furnished withtwo snap-rings. The valve is a hollow piston-valve, with cast-iron ends, made very light, with a body of steel tubing. It… … 1- i(i. 40.—Valve and cylinder.
