Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 442
14 showin some detail, from two direc-tions, the mechanism that is above the table, and that is associated with the binding function.Reaping Mechanism.—Fig. 15 shows the relation of the binder portion to the reaper por-tion of the machine. At the rear of the binder-table is a spring wind-board,… … Fig. 13.—Knotter—driving parts.
Mechanical engineering
