Fig. 3.—Leather-link belt. … Leather-link belt. more completely than .solid leather belts, and this quality assists them in the transmission ofpower. The proper manner of running a link-belt is illustrated in Fig. 3. Here the belt isdrawn taut upon the under side, allowing the u|)ppr side to sag and climb the driven i)ulley,so…
