Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 720
es and tangential tips to the vanes are found insuch cases to be of practical value so far only as they tend to obviate friction and consequentslight loss of power. The diaphragm above the upper runner is a plain flat plate ; but theintermediate diaphragm between the two runners is made with fixed… … FiG. 5. Fig. 4.Irrigating machinery.—Compound centrifugal pump. Details. vided in the top cover at 11, Fig. 6, for convenience of attacliing additional suction pipes indifferent cases ; but it is not often that all four inlets are required. The delivery valve isarranged to swing clear of the…
Mechanical engineering
