Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 128

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 128
hinged to chains runningover sprocket wheels and guided in groovesin the sides of a casing. By the use of alarge number of inclosed buckets closelyfitted, an efficiency of 90 per cent isclaimed. This claim is doubted in consid-eration of the friction of the many bucketsin the tube, their loose… … to match the buckets. The water flow is governed by the opening orclosing of a sector slide valve controlled by a fly governor.300. Elevation, showing position of nozzle and buckets. 128 HYDRAULIC POWER AND APPLDVNCES.
