Fio. C—The Reniiie boiler. BOILERS, STEAM. 59 Semi-Portable Boilers.—The Economic Boiler. The boiler shown in Fig. 7 is madeby the Erie City Iron Works, Erie, Pa. It has been given the trade name of the ■ Economic. … Fig. 7.—The ecouoiuic boiler. The front end of the boiler is cylindrical in form and extends over the furnace, forming thecrown-sheet. The rear end is oval, the lower portion extending below far enougli to hold theshort tubes leading from the furnace to the back connection. The furnace is…
