, and the firstone was used on experimentson the New York elevatedrailroad in 1886. The ma-chine (Figs. 5 and 6) consists,in brief, of two curved field-magnets bolted to two polepieces, the whole carried bybrackets on each side, whichbrackets center on the axleand also carry the armature.The free… … Fig. 5.—Sprague motor.
