Fig. 5.—Ingot a.* cast. … Fig. 6,—Ingot and slitting rolls. ROLLS, METAL WORKING. 747 correspond with those on the outside roll, but shorter. Fig. 7 shows an ingot after the tophas been sheared oif and the remainder cut into tire blooms ready for finishing. In Fig. 8 a perspective view of the mill is given. It consists ofan…
