entirely removes thestrain and jar of the operating parts from the electro-magnet, and reduces the friction in its armature bar toa very trifling amount, thus insuring great freedom in itsaction. On the main spindle of the machines a threadof a very fine pitch is cut where it projects through… … 7) Fig. 8.—Union signal. Mechanism.
