red, may be lifted off on a slip of pa-per and transferred to body plan construction lines, when thereshould be no difficulty in drawing in freehand the sections, havingthe dead flat section as one extreme guiding curve and thetransom frame as the other. 8th. After the preceding sections have been… … 32 FT. W. L. ELEMENT COEFFICIENTS AREA OF MID. SECT. 3 = .898 BLOCK CO-EFF. A = .fiee PRISMATIC CO-EFF. . _p = .742 AREA OF L. W. L. (I = . 771 BILGE DIAGONAL b = .723 RELATION CO-EFF. £ = .985 Fig. 15. to eye with the guide spots mentioned, the planimeter should boused to take a trial…
