A new and original treatise on the geometrical development of round and oval cones, with easy examples of their application : for the use of beginners and practical sheet iron and tin plate workers (1904)

Fuller, John, b. 1833 · New York : D. Williams · leaf 20

An illustration from A new and original treatise on the geometrical development of round and oval cones, with easy examples of their application : for the use of beginners and practical sheet iron and tin plate workers, 1904, leaf 20
ameter will make the pattern required,the depth of the pan being added or subtracted fromthe radius as the case requires. Many other examplescould be given to illustrate where this fashion can be andis used in the construction of many articles called forand made in a country shop, where most people…

Sheet-metal · Geometry, Descriptive

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
