Notes and examples in mechanics; with an appendix on the graphical statics of mechanism; (1903)

Church, Irving P. (Irving Porter), 1851-1931 · New York, J. Wiley & sons; [etc., etc.] · leaf 141

An illustration from Notes and examples in mechanics; with an appendix on the graphical statics of mechanism;, 1903, leaf 141
guous particles were sud-denly to be restored, system (II.) still acting, the motion of theassemblage of particles would not he affected (precisely as the fall-ing motion in vacuo of two wooden blocks in contact is just thesame whether they are glued together or not) and consequently weargue that… … 132 NOTES AND EXAMPLES IN MECHANICS. Since the resultant of system (II.) is a single force, = Mp^parallel to the direction of the acceleration, it follows that theresultant of the actual system is the same. 116. Angular auantities—Rotary Motion about a Fixed Axis.—In Fig. 155 let the body J/ZiV^…

Mechanics, Applied · Engineering · Graphic statics

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
