Notes on practical mechanical drawing, written for the use of the students in general engineering drawing in the University of Illinois (1907)
Wilson, Victor Tyson, 1864- [from old catalog] · State College, Pa., The author · leaf 22
Line in the view,horizontal lines first and then vertical lines. Lay out the elevation in the same manner as the plan.Put on limiting lines, arrow heads and figures in the ordernamed. In inking, rule the horizontal outlines of all the viewsfirst, beginning at the top and going down. Rule the… … 14 Notes on Practical Mechanical Drawing 10. Detailed directions for pencilling and inking Exercise No. 5. Draw the plan view first, laying out center line, scalingthe length over all and the width of each end, then enclosingby lines. Draw the elevation next, and then either end.After this put on…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
