commercial sizes of standard spriug cotters is as follows: Diameters from ^ to ^ vary by 64thsof an inch, from | to V by 16ths of an inch and from J to f by Sths of an inch. Lengths from h to 4 varj^by 4ths of an inch and from 4 to 6 by inches. Pins -^ in diameter, range in length from J to 2. Pins… … 43PIPE CONNECTIONS FIG. ii 129. Ordinan- Standard wrought iron pipe is designated by its nomiaal inside diameter. Thus a 12 pipe is just 12 in internal diameter, whUe a | pipe is .269 in internal diameter. See Table 3 for properties. Extra and Double Extra pipe are of the same outside diameter as…
