Notes on technical sketching and free hand lettering for engineering students (1912)
Smith, Alton Lincoln, 1867- [from old catalog] · Worcester, Mass., The author · leaf 14
perspective drawingin which the eye is placed at a great distance from the object. 10. In Fig. 6, A, the cube, ABCD-H, is elevated shghtly from the table and turned so aU its edgesare obhque to the plane of projection. It is also placed so its upright edges are aU parallel to a side plane,not…
