On yacht sailing : a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861-1927 · New York : Rudder Pub. Co. · leaf 83
SAIL PLAN OF CAT BOAT. 79 SAIL PLAN OF CAT BOAT. 1— Mainsail. 2— luff. 3— leach. 4— head. 5— foot. 6— Mainsail throat. 7— peak. 8— tack. 9— clew. … 8i SPAR AND RIGGING PLAN OF SLOOP. 1— Freeboard. 2— Rail. 3— Mast. 4— Main boom. 5— Gaff. 6— Bowsprit. 7— Bobstay. 8— Strut. 9— Main sheet. 10— Peak halyards. 11— Throat 12— Topping lift. 13— Lazy jacks. 14— Preventer or shifting backstay. 15— Gaff jaws. 16— Boom jaws or goose- neck. 17— Shroud to…Yachts · Yachting
