On yacht sailing; a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861- [from old catalog] · New York and London, The Rudder publishing company · leaf 79
DIAGRAM D. BOAT, FROM I TO 6, IS BEARING AWAY OR KEEPING OFF FROM THE WIND ; BOAT, FROM 8 TO13, IS LUFFING OR NEARING THE WIND. 75 DIAGRAM C. I—Close-hauled on port tack.2—Wind forward of the beam.3—Wind abeam. 4— abaft the beam. 5— on the quarter.6—■ * astern. 7—• dead astern. 8—Jibed over to… … SPAR AND RIGGING PLAN OF CAT BOAT. 77 SPAR AND RIGGING PLAN OF GAT BOAT. I—Hull. 2—Cabin house. 3—Main mast. 4— boom. 5- gaff. 6—Companionway hatch.7—Main sheet.8—Topping lift.9—Lazy jacks. or lo—Peak halyards. 12— bridle. II—Throat 13—^Jaws of gaff. 15—Head stay. 16—Shroud. 17—Strut. 18—Bitts.…
