Putnam, J. Pickering (John Pickering), 1847-1917 · Boston, Ticknor and Co. · leaf 246
m, as inFig. 217. But the difficulty of the artistic handling is proportionatelyincreased, and the rough sketch is presented merely as a suggestion fordevelopment under more careful study or a more skilful hand. Thescreen here surrounds the entire base of the radiator, and the uprightflues unite at… … Fig. 218. Distributor as Open Radiator. Horizontal Section. fresh air and of the heat-rays is clearly indicated by arrows and dottedlines. In all but one of the above designs, though the majority of thechimne}r-breast is taken up by the radiator, a certain amount of space isstill left for…
Fireplaces
