Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 126
sindicated in Fig. 188, PATTERN MAKING 109 Glue 1-2-inch stock together, to make the hub 12£ inches indiameter by 5 inches long. Plane one end true, bore a 1-inch holeat the center, and, after band sawing to a rough diameter, fastento a faceplate having a lrinch pin at its center. Turn to the…
