Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 135
Fig. 199. Section of Pattern for Faceplate, Fig. 19S Fig. 200. Core Box for Faceplate Slots diameter is more than two feet, the grain of stock used in theweb should be parallel to the radius. Each sector as it is fittedshould be screwed to the wood faceplate, leaving a space of -^ inchbetween each… … Fig. 20,1. . Tee Pipe Fitting Fig. 202. Section of Tee pleted; one extra rib should be furnished the molder for mendingup the mold. Leather fillets are to be used in the corners made by PATTERN MAKING 119
