Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 386
l Force-- Fig. 343. — Extra HeavyCast-Steel Fittings. V -Flange f. • Straight Face .* Fig. 344.—Low-Pressure Cast-iron Fittings. pressure cast-iron fittings (Fig. 344) are suitable for steampressures up to 25 lb. per sq. in. They may be used inexhaust-steam systems. Their use in live-steam… … Skelp-Fig. 345.—Method Of Forming Butt-Welded Pipe. struction: (1) Butt-welded. (2) Lap-welded. (3) Riveted.In the making of butt-welded pipe (A-Fig. 345) the squarededges of the skelp, B, are brought to a welding heat. Theend of the pipe is then formed C- and the edges are pressedtogether D- by…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
