Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 89
method whichhas some advantages is thatshown in Figs. 147 and 148. Select stock with a width of about 1inch greater than the diameter of the required core, with the depthabout half this width, and the length slightly longer than the totallength of the pattern, including the core prints h. Dress… … Fig. 145. Skeleton View of Machine Saw withTable Tilted to 45 Degrees PATTERN MAKING 73
Patternmaking
