Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 72
.V.,A C. V., B C. V.; also O MP and M MP. From points K, H,where B C.Y. intersects O MP and M MP, erect KN and HGparallel to BD ; and through N, G draw NE and GF paral-lel to CD. Draw EL ±_ to EN and KL _L to EL, whichwill complete the plinth. For BK = BO and KH = OM ; thenEF = NG - KH = OM = 4,… … Fig. 40. Here take A, 4 to right of E. and B 4 to right of A ; onAB describe square ABDC, and divide it into sixteen equalsquares ; join each angle, as shown in figure, with the C. V.;join also E MP, cutting A C. V. in F; draw FG parallel toAC, GS J_ to GF, etc. Then FG = AK - 1, and GS = KN= 1,…
Geometrical drawing · Perspective
