fixed. A cone is formed by the revolution of a right-angledtriangle around one of the containing sides, which remainsfixed. A cylinder is formed by the revolution of an oblong aroundone side, which remains fixed. A spheroid is formed by the revolution of a semi-ellipsearound one of the axes, which… … THE CUBE. 67 Example 1,—Draw a cube, edge 4, placed on G.P., one sideparallel to P.P. and 2 within it, near angle 3 to right. H = 6; L.D. = i\ scale ^ = V, Draw B.L., H.L., and O, C.Y. and find IMP as before.Take A 3^ to right, and B 4 to right of A; take 0 2 to leftof A, and D M to left of 0; join…
