Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thomas H. [from old catalog] · Toronto, W. Briggs; · leaf 81
Fig. 44. 76 DRAWING. Example 2.—Draw a cylinder lying on G.P., 4 to right,having end perpendicular to P.P., and touching it; cylinder8 long and 3 in diameter. … Ta^^e A, 4 to right and E, i to left; make AB = 1^-, anddescribe circle; join B C.Y. and A C.V., also E MP, and fromC, draw CD parallel to AB, and describe smaller circle; thendraw common tangents, completing the cylinder. (Pig. 45.) THE CYLINDER. 77 Example S.—The figure shows how to draw a common…
Geometrical drawing · Perspective
