The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1870)
Auchincloss, W. S. (William Stuart), 1842-1928 · New York : Van Nostrand · leaf 45
ith economy of action. On this accountthe single eccentric is rarely used to effect cut-offs of lessthan | the stroke. Earlier cut-offs require two valves andtwo eccentrics, the one set for regulating the cut-off of thesteam, the other its admission and escape. This subjectwill be more fully… … *M EXHAUST CLOSURE ANGLES. 180 CUT OFF ANGLES To the Reader.—A. Cop-per-plate engraving of theTRAVEL SCALE will befound attached to the backeovcr. CEANK AND VALVE MOTIONS. 37 Let EFD represent the path traversed by the centre ofan eccentric whose throw equals 3J inches, consequentlythe travel of…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
