The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1870)
Auchincloss, W. S. (William Stuart), 1842-1928 · New York : Van Nostrand · leaf 54
0°=0.82the entire stroke. A moments reflection will also show that—during theprogress of the crank—the varying width of the port open-ing from the simple lead out to the maximum width andback again to the period of cut-off, might readily be tracedon the Scale, and all the information common to the… … Fig. 11. i t \1 \ 1 \1 \ > 1 1 1 I J NEUTRAL POSITION. \% i i /i /; / ! / y ,4—-■ To toe Reader.—C«< MlS/>Z<7te i« tivo through C C theline of the Valve Face . By sliding the valve pieceback and forth over its ports, avery clear idea will be obtainedof the relative positions of theedges…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
