Fig. 54 Exercise 30.—Ionic volute. Figs. 51, 52, 53 and 54.Fig. 51 is an illustration of the volute spiral of an Ioniccapital in classic architecture (Fig. 54). In laying 56 A PRACTICAL COURSE IN out such a curve, either method. Fig. 52 or Fig. 53,may be used with the same results. When AB is… … Fig. 55 the semi-diagonal of the square into three equal partsand construct squares through these points, as in Fig.52. Each corner of these squares is a center for quad-rants of the outer spiral starting with radius A. Theinner dotted squares are drawn to pair within thefirst squares, a distance…
