Fio-. 162.-Sketch of Cuhe. Fio 163.—Geometrical Constractionof a Cube. line from the centre line at top of stack down the wide face tomeet the ridge, and join up the intersection lines as shown inFisj. 161. … Fig. 164.—Method of Constructing Isometric Scale. Before concluding this chapter on angular projection, it willbe interesting to see the principles and application of true iso-metrical projection. It is based upon orthographic projection—that is, the rays of light proceeding from the outlines of…
