step. It is fittedto the runner by aRyne, made on thebalance principleThe top of the spin-dle is sphericallyshaped, as at o, be-ing passed throughthe collar disc, p,and fitted into aspherical recess inthe under side of theRyne, q, connectedto the stone, a. Inthis way, as the con-nection between… … THE PRACTICAL DRAUGHTSMANS scale. A is the base i)lato, and li the lower running stone, drivenfrom above by the main spindle, i, which passes down through thecentre of the adjustable tubes of the feed-hopper, and terminatesin a convex foot. This foot rests in a concavity in the top ofthe disc…
