The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing (1854)
Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Cory, William Johnson, 1823-1892 · New York, Stringer & Townsend · leaf 275
pinion, n,out of gear by means of an eccentric, whilst I and h are connectedby change-wheels. In the same way, face-cams and other formsmay be shaped by varying the connections. Angular and diagonal work in any position may also be workedin this lathe without tilting the tool, by means of the same…
Decorative arts · Drawing
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
