ing-point, P, to which the handle, H, isattached by a universal joint. The frame, f, also carries a wheel, I,which, by means of a weight, is pressed on the surface of thecone, and receives motion from it as the tracer is carried along the paper. The index-wheel, I, only touches the cone by a… … these divisions is the Tooth part of a square inch; so that one turnof the wheel represents 20 inches. Another index-wheel, t,moved by I, is divided into five parts, each of which represents20 inches, so that a complete revolution of T values 100 inches.The eye-glass, e, assists in reading the…
