Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 135
onautical motor are ofthe L type and are cast separately with the cylinder barreland water jacket in one integral casting. A special iron isused for these castings that has an ultimate tensile strength of40,000 pounds per square inch. The valves which are easilyaccessible through valve covers, are… … Fig. 41. Six Cylinder Sturtevant Aero Motor. of cams. A bronze gear fitted on the cam shaft meshes witha gear on the crank shaft without intermediate idlers. Like the cam shaft, the crank is bored out from end to endwith a propeller flange applied on a taper at one end of theshaft. A bearing is…
Internal combustion engines · Traction-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
