Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 184
--■ GAS, OIL AND STEAM ENGINES 179 fies the type FH as a semi-Diesel, while type HA comes underthe head of that class of engines known as aspirators. Semi-Diesel (Type FH) During the suction stroke, air is drawn into the cylinderthrough the inlet valve located on the top of the cylinder head,and on… … 76-b. Cross-Section of Type F H, De La Vergne Oil Engine. to about 300 pounds per square inch in the combustion cham-ber. The compression heats the air to a high temperaturewhich is still further increased by contact with the hot wallsof a cast iron vaporizer D, shown by Fig. 76-b. At the…
Internal combustion engines · Traction-engines
