Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 399
359 64 KNIT GOODS FINISHING The mechanism, for chiving the cloth-feed rolls, of which 31 is one,is as follows: 21, 22 and 23 are sprocket-wheels fast to the main shaft.21, 22, and 23 are corresponding sprocket-wheels fast to the … counter-shaft 24. 45 is the sprocket-chain, by shifting which fromone pair of said sprocket-wheels to another the speed of the counter-shaft 24 may be varied with respect to the speed of the napping-cylinder. 25 is a pinion fast on the shaft 24 and which drives a gear 360 KNIT GOODS FINISHING 65…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
