Hale, Joseph W. L. (Joseph Woodwell Ledwidge), 1886- · New York [etc.] McGraw-Hill book company · leaf 188
Fig. 143. 46. Find the length of plank required to reach from A to B,as per Fig. 141. 47. In Fig. 142 with crank pin on the top quarter the distancefrom center of driver to center of cross-head is 83%2 in. Themain rod is 84 in. long. Find the angle a and the stroke of theengine.
Mechanics, Applied
