Hale, Joseph W. L. (Joseph Woodwell Ledwidge), 1886- · New York [etc.] McGraw-Hill book company · leaf 232
oss section ofthe material. The blocks shown in Fig. 196 represent about the STRENGTH OF MATERIALS 217 limit of the size of pieces used in compression tests. Apiece should not be longer than 6 times its diameter,else a bending may occur along with the compression. The forms used for bending and… … Fig. 196. ^ a Fig. 197. 83. Values of Ultimate Strengths.—From the resultsof tests with these machines the following table showsthe average values of ultimate strengths of the mostused materials and for the kind of stress indicated. Ultimate Strength in Pounds per Square Inch Material Tension…
Mechanics, Applied
