rfaces are dark; hence the edgeswhich are between the light and dark faces are the shade lines. Whenever it is more convenient, a plane parallel to the rayof light and perpendicular to H may be taken, the section foundin elevation, and the 45° triangle applied to this section. Thesame method may be…
