arings in the casing C. The equiva- 144 MECHANICAL DRAWING lent pitcii circles of the plates or pistons are rep-resented by the two chain-dotted circles of equaldiameter; and the sides of the casing are atcs ofcircles having P^ and Pg as centers. The pistonsare, therefore, always in contact with…
