Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 50
Fig. 117. … Fig. 118. ley is equal to the product of the weight by thediameter of pulley. In the arrangement shown atFig. 118 the power is equal to one-half the weight.A combination of movable pulleys with separateand parallel cords is shown at Fig. 119. Eachsystem reduces the resistance to the extent…
Mechanical drawing · Machine design
