Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 218

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 218
solid on AB. (1888) 36- The plan and elevation of a desk are given. Draw a frontelevation on a line parallel to x^yv (1886) *37. Make a sectional elevation on AB of the desk. (1886) 38. Draw the plan of a square prism, height 2§, side of base\\, a diagonal being vertical. (1891) 39. ABC is the base… … CHAPTER IX THE STRAIGHT LINE AND THE PERPENDICULAR PLANE 175. The possible positions of a line.—The variouspositions which a line, situated in the first dihedralangle, may have, relatively to the planes of projection, areshown lettered (a) to (n). The remaining lines (o) to (/) are wholly or…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
