Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 340

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 340
elevation of the section made by a vertical planeparallel to, and distant i- from the axis. 3. Draw a triangle a! bc with bc in xy ; make bc 3, ab 4, and ac 2^. This is the elevation of a cone, the plan of whoseaxis makes 400 with xy. Determine the horizontal trace ofthe cone. See Prob. 276. 4. A… … x a. b

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
