motion gives the easiest working cam.The follower has the same motion as a falling body. The distance passedover is proportional to the square of the time. The distances on thetravel of the follower are made proportional to 1, 3, 5, 7, etc., and reverseas shown at IV, Fig. 214. GEARS AND CAMS 123…
