a Dojne by the First Method.—Let ABC (Fig.41) be the section of a dome. Draw the axis DB; pro-duce to J; divide the curve of one-half the figure into … equal i)arts, as EFG and H, the>width of these divisionsbeing the width required by that of the metal with which S2 TIN, SHEET-IRON AND COPPER-PLATE WORKER. the dome is to be covered; produce AE, EF, FG, GHand HB severally, until they intersect the axis BD; then[for example] from the point I,…
