Addyman, Frank Thornton · London : Scott, Greenwood & co. · leaf 108
rface. This is supported horizontally between two metallicuprights, + B - B, which are connected with the two terminals INDUCTION COILS. 79 of the battery. Each of these uprights has a metallic connec-tion, the details of which are shown in II., with one of thecopper strips. The ends of the primary… … l3 - n -c + c ±n Cr=^ Fig. 28, I. and II.—Current Reverser. battery, when the handle is in the position shown in the figure+ C is in connection with + B. By turning the cylinder, A,through half a revolution, + B is brought into contact with- C, and the current through the primary thus reversed.When…
X-rays
Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
