Principles and practice of electrical engineering (1914)
Gray, Alexander, 1882-1921 · New York [etc.] McGraw-Hill Book Company, inc. · leaf 257
ving field, then three separate single-phase e.m.fs. may beobtained, one from each winding. If further these stators aremounted so that Sh S2 and >S3, the starts of the windings of thethree phases, are spaced 120 electrical degrees apart, then thee.m.f. in winding B will reach a maximum 120… … Fig. 257.—Three single-phase stators.
Electrical engineering
