The principles underlying radio communication (1922)
United States. National Bureau of Standards, Ould, Richard Sheldon, 1889-, United States. Army. Signal Corps · Washington, Govt. Print. Off. · leaf 167
construction generally used onlarge machines, one reason being that it makes the armatureeasier to insulate. But it is also possible to have the field mag-nets stationary while the armature is made to revolve. Small 164 DYNAMO-ELECTRIC MACHINERY. The principle is sho^^Tl in machines are often built… … Fig 103.—Circuit diagram of revolving-armature alternator. A, arma-ture ; F, frame; P, poles ; R, collector rings ; B, brushes ; TT, termi-nals of field circuit; XX, leads to external circuit. When a is passing under the A^ pole, coming toward the reader,the electromotive force in it is to the…
Telegraph, Wireless · Radio
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
