Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)

Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 73

An illustration from Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils, 1920, leaf 73 — SA, form SSI, frame No. 137,Fig. 24, will be used in this design. The design of this framewill be treated later as a separate problem, it being assumed thatthe line of standard frames given in Fig. 25 is available. Theseframes are all intended to carry a main winding and a startingwinding which is… … PRIMARY-36 SLOTSSLOT DEPTH ^.4-SnAVE WIDTH ^J97f5L0T OPENING =.10TOOTH NECn ^ JO SECONDARY59 5L0TS5L0T DIA. - .I95fSLOT OPENING^ .05f^ SCALE: HALF SIZE Fig. 24. Details of Western Electric Type SA, Frame 137 Motor | 1800 r.p.m., or 30 revolutions per second, and the frequency 60cycles, there will…

Electric motors · Electric transformers · Electromagnets · Induction coils

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
