for steam or hot water, and in Fig.17 (B) for hot air. The specifications should s E:C2 Puooas rig. 18. Conventional Representation of Flues for Air Supplyand Ventilation. 252 ARCHITECTUEAL DEAFTING describe the kind of heat, and go into detailabout pipe, fittings, etc. In hospitals, public… … Pig. 19. Sketch Plan Showing Arrangement of Pumiture. The method of figuring the correct location forsuch work will be considered under Heatingand Ventilating. The conventional method ofshowing flues for air supply and ventilation isshown in Fig. 18. For furniture, certain conventional forms…
