lan (A145)the tank is shown in the dotted lines. Itis placed ten feet above the ground and thetank itself is fourteen feet high by ten feetin diameter at the bottom. TOWER TANK HOUSE —A145 In placing a tank like this it is necessaryto carry a three inch pipe through the tankand pass the pump shaft… … T/JNH tiOUS£: at the top and the shaft must have a bear-ing, bothabove the tank and below it soit wont scrape on the pipe. The well andpump of course are directly under the tankin the center of the tower. The outside boarding is made doubleand lined with paper to be warm in winter. There is…
